| G.V.W. |
2,090 Lbs |
| Curb Weight |
451 Lbs |
| Payload Weight |
1,639 Lbs |
| Tire Rating |
5.30 x 12c Load, 6 Ply |
| Tire / Wheels |
12" Tires rated 1,050 Lbs each |
| Axle |
Solid square tube 2,000 Lbs |
| Coupler |
2" |
| Bed Length |
88" Extended |
| Bed Width |
52" |
| Overall Length |
172" Extended |
| Overall Width |
69" |
| Floor Height |
20" |
| Hitch Height |
16" |
| Texture |
Black Powder Coated |
• 100% Corrugated steel floor.
• 2 position, Dump bed extends additional 56" for oversized cargo hauling.
• 2 position, Tongue extends additional 24".
• Removable side panels.
• Fully welded heavy-duty steel tube frame.
• SAE straight coupler with safety chains.
• 3-Leaf springs.
• LED Lighting complies with all DOT requirements, Includes 2 hevay-duty light protectors.
• Silver Wheel.
• Assembly manual.
